Three Wheeler Electric Loading Vehicle Series
Introducing our latest series of three-wheeler electric loading vehicles, perfect for efficiently transporting a variety of cargo. Don’t miss out on this opportunity; seize the offer today!
For your convenience, these vehicles are also available through easy instalment plans provided by Faysal Bank. Take advantage of this exceptional offer and streamline your transportation needs effortlessly.
![](https://greenlandmotorspk.com/wp-content/uploads/2024/06/Three-Wheeler-Electric-Loading-Vehicle-Series.jpeg)
1.
GLM – Khalid
Three-wheeler electric loading Vehicle (Khalid) is powered by batteries, which is economical and environmentally friendly, and has a beautiful appearance.
2.
GLM – Babar
Three-wheeler electric loading Vehicle (Babar) is powered by batteries, which is economical and environmentally friendly, and has a beautiful appearance.
3.
GLM – Yasoob
Three-wheeler electric loading Vehicle (YASOOB) is powered by batteries, which is economical and environmentally friendly, and has a beautiful appearance.
Experience The Future Of Mobility With Greenland Motors.
Reach Out Today For Unparalleled Insights And Service.
Descriptions | Model | BABAR Parameters 50 KM | KHALID Parameters 100 KM | YASOOB Parameters 130 KM | |
Vehicle Overall Parameters | Payload | kg | 400 | 1000 | 1000 |
Dimensions | mm | 3000*1080*1330 | 3120*1180*1260 | 3360*1230*1450 | |
Length | 3000 | 3120 | 3360 | ||
Width | 1080 | 1180 | 1230 | ||
Height | 1330 | 1260 | 1450 | ||
Wheelbase | 860 | 960 | 2130 | ||
Body length | cm | 150 | 160 | 180 | |
Wheel tread rear | mm | 2000 | 2020 | 1150 | |
Minimum ground clearance | mm | 15 | 15 | 15 | |
Traveling Parameters | Cruising Range | km | 50 km | 100 km | 130 km |
Max. Speed | km | 45 | 45 | 50 | |
Max. claiming angel | % | ||||
Braking Distance | m | 2 | 2 | 3.5 | |
Min. turning diameter | m | ||||
Chassis | Construction Material | steel | steel | steel | |
Drive motor power | km | 1500WD | 2000WD | 2000WD | |
power supply | v | 60/72V | 60/72V | 60/72V | |
speed control | 48/60V30 tube G | 60/72V30 tube G | 60/72V30 tube G | ||
Battery | Lead acid battery | Lead acid battery | Lead acid battery | ||
Type | Acid / Lithium | Acid | Acid | Acid | |
Volume | AH | 60V58AH | 60V80AH | 72V100AH | |
Charging time | hrs. | 6-8H | 6-8h | 6-8h | |
Front / rear axels | Aluminum cylinder external spring shock absorption Spring steel plate | Aluminum cylinder external spring shock absorption Spring steel plate | ะค43outer spring Hydraulic shock absorption of aluminum cylinder Shock absorption of leaf spring | ||
Braking Method | Integrated Handbrake | Integrated Handbrake | Integrated Handbrake | ||
Tyre & Rim Specification | Front 350-12 Rear 375-12 | Front & rear 400-12 explosion-proof tires | 3.75-12Inner and outer tire 4.00-12Inner and outer tire | ||
Body Parameters | Material | steel | steel | steel | |
Dimensions | mm | 3000*1080*1330 | 3120*1180*1260 | 3360*1230*1450 | |
Length | 3000 | 3120 | 3360 | ||
Width | 1080 | 1180 | 1230 | ||
Height | 1330 | 1260 | 1450 | ||
Curb Weight | Complete three-wheeler | kg | |||
including body & batteries | 190 | 276 | 348 |
